19mm Laser Beam Adapters, Clamps, Mounts, Beam Tubes

Laser Beam Delivery Laser Bezel Adapters

19mm Laser Accessories & Adapters

Haas standard accessories and adapters for our 19mm series laser delivery systems. Custom retro-fit solutions are available, contact a Haas Laser Engineer.



Coherent Diamond K-Series

    Part #   USE
ADP-K500-CMNT Coherent Diamond K-Series Mount   ADP-K500-CMNT   Threads to Laser Bezel   ADP-K500-CMNT Coherent Diamond K-Series Mount
  Provides a method to rigid mount BT-19 Beam Tubes to lasers, flanges, mounting plates, etc...
            Download Technical Drawing



Universal 1"-32 Mount

    Part #   USE
ADP-UNIV1-CMNT Universal Mount   ADP-UNIV1-CMNT   Bolts to Modified Laser Bezel   ADP-UNIV1-CMNT Universal Mount
  Provides a method to rigid mount BT-19 Beam Tubes to lasers, flanges, mounting plates, etc...
            Download Technical Drawing



For Use with BTA Threaded Beam Tubes

    Part #   USE
ADP-19-CMNT Use with BTA threaded beam tubes   ADP-19-CMNT   Threads to Laser Bezel   ADP-19-CMNT Use with BTA threaded beam tubes
  Provides a method to rigid mount BT-19 Beam Tubes to lasers, flanges, mounting plates, etc...
            Download Technical Drawing



Synrad

    Part #   USE
ADP-S48-CMNT Laser Bezel Mount Synrad   ADP-S48-CMNT   Bolts to Laser Bezel   ADP-S48-CMNT Laser Bezel Mount Synrad

            Download Technical Drawing



Universal Laser Systems

    Part #   USE
Universal Laser Systems, UL-XX-OEM, ADP-UNIV2-CMNT, Replaces laser bezel   ADP-UNIV2-CMNT   Replaces Laser Bezel   Universal Laser Systems UL-XX-OEM ADP-UNIV2-CMNT Replaces laser bezel

            Download Technical Drawing



Coherent Bezel Mount

    Part #   USE
Coherent Bezel Mount ADP-TM-C30/55   ADP-TM-C30/55
  Coherent C30/C55  Bezel Mount, with C-Mount and Bolt Pattern
            Download Technical Drawing



Additional options available upon request

We would be happy to discuss a custom designed solution that's right for any project, large or small. For additional information, contact a Haas Laser Technology sales representative today. (973) 598-1150



** Specifications subject to change without notice. Consult a Haas Laser Tech engineer for the latest specification changes or any additional assistance. **
