50mm Laser Process Head Assembly
-
Fiber laser process head designed for high power laser applications. The unit can be used with any high-power fiber laser. The modular design permits use with a wide variety of fibers and optic combinations. Custom proprietary optical component design greatly reduces internal power loss. Custom configurations available. Robust industrial design.
- 50mm optics with a 47mm C.A.
- 20kw Power Handling Capacity
- Modular Design
- Water-Cooled High Power Optics
- Several Fiber Adapters Available for all Lasers
- Anodized Aluminum, Stainless Steel & Brass Construction
- Gas Jet, Air Knife & Cover Glass options
- Robust Industrial Design
-
Collimation Options
- Focus lengths of 100mm-200mm avaliable
Viewing Module Options
- Viewing module option
- Viewing with CCD camera and monitor
- Viewing with Binocular or Monocular
- Nonviewing module option
Downloads
Base Focus Module
- 120mm f.l. and longer options avaliable
- Contains removable cartridges for focus lens and cover glass
- Uses 1/4-80 XY adjustment screws
- Max. pressure 25 bar with 1/4" thick fused silica cover glass
- Accommodations for 50.8mm (2.0") dia. focus lens and cover glass.
- Options for capacitive hight sensing
- Many additional options available
Air Knife Options for Welding Applications
- Air Knife is used in laser welding applications to prevent optic damage from splatter, requires air at 30-80psi.
- Many configurations available.
Nozzle Tip Options for Cutting Applications
- Tip Stand Off Adjustment Options
- Capacitive Height Sensing Nozzle Body Options
- Standard Nozzle TIp Options
